Datasheet

TEK.COM

18

True RMS AC Voltage and AC Current

Function

Resolution

1-Year Accuracy: ±(% of reading + % of range) T

3 Hz to

5 Hz

5 Hz to

10 Hz

10 Hz to

20 kHz

20 kHz to

50 kHz

50 kHz to

100 kHz

100 kHz to

300 kHz

100.0000 mV

0.1 µV

1.0 + 0.03

0.30 + 0.03

0.06 + 0.03

0.14 + 0.05

0.6 + 0.08

4.0 + 0.5

1.000000 V

1 µV

1.0 + 0.03

0.30 + 0.03

0.06 + 0.03

0.14 + 0.05

0.6 + 0.08

4.0 + 0.5

10.00000 V

10 µV

1.0 + 0.03

0.30 + 0.03

0.06 + 0.03

0.14 + 0.05

0.6 + 0.08

4.0 + 0.5

100.0000 V

100 µV

1.0 + 0.03

0.30 + 0.03

0.06 + 0.03

0.14 + 0.05

0.6 + 0.08

4.0 + 0.5

700.000 V

1 mV

1.0 + 0.03

0.30 + 0.03

0.06 + 0.03

0.14 + 0.05

0.6 + 0.08

4.0 + 0.5

Temperature

Coefficient/°C

(all ranges)

–

–

0.01 + 0.003

0.03 + 0.003 0.005 + 0.003 0.006 + 0.005 0.01 + 0.006

0.03 + 0.01

Function

Resolution

1-Year Accuracy: ±(% of reading + % of range) T

3 Hz to 5 Hz

5 Hz to 10 Hz

10 Hz to 2 kHz

2 kHz to 5 kHz

5 kHz to 10 kHz

1.000000 mA

1 nA

1.0 + 0.04

0.30 + 0.04

0.08 + 0.03

0.09 + 0.03

0.09 + 0.03

10.00000 mA

10 nA

1.0 + 0.04

0.30 + 0.04

0.08 + 0.03

0.09 + 0.03

0.09 + 0.03

100.0000 mA

100 nA

1.0 + 0.04

0.30 + 0.04

0.08 + 0.03

0.09 + 0.03

0.01 + 0.006

1.000000 A

1 µA

1.0 + 0.04

0.30 + 0.04

0.20 + 0.04

0.88 + 0.04

0.01 + 0.006

3.000000 A

1 µA

1.0 + 0.05

0.30 + 0.05

0.20 + 0.05

0. 88 + 0.05

2.0 + 0.04

10 µA

1.0 + 0.05

0.40 + 0.05

0.40 + 0.05

0. 88 + 0.05

2.0 + 0.05

Temperature

Coefficient/°C

(all ranges)

–

–

0.10 + 0.004

0.030 + 0.004

0.005 + 0.003

0.006 + 0.005

0.006 + 0.005

Additional AC Uncertainties – Low Frequency Uncertainty

Additional Uncertainty

±(% of reading), Lower

Frequency Uncertainty

Detector Bandwidth (BW)

3 BW

(3 Hz to 300 kHz)

30 BW

(30 Hz to 300 kHz)

300 BW

(300 Hz to 300 kHz)

20 Hz to 30 Hz

0

0.3

—

30 Hz to 50 Hz

0

0

—

50 Hz to 100 Hz

0

0

4.0

100 Hz to 200 Hz

0

0

0.72

200 Hz to 300 Hz

0

0

0.18

300 Hz to 500 Hz

0

0

0.07

> 500 Hz

0

0

0

NOTES

83. 20% overrange on AC functions except 1% on 700 V, 3.33% on 3 A, and 1% on 10 A. Default resolution is 6½ digits.

84. Specifications are for detector bandwidth of 3Hz and sine wave inputs >5% of range. Detector bandwidth of 3 Hz and 30 Hz are multisample A/D conversions. Detector bandwidth of

300 Hz is a single A/D conversion, programmable from 0.0005 PLC to 15 PLC (60 Hz), 12 PLC (50 Hz). Default condition set to 1 PLC.

85. Rear terminals only.
