DMM 7510 7½-Digit Graphical Sampling Multimeter

Capacitance

Accuracies specified for additional cable and stray capacitance properly zeroed with the Rel function.

Accuracy

Resolution

Charge

Maximum

Circuit Voltage

Accuracy

±(% of reading + % of range)

2 years

T

Temperature

1.0000 nF

0.1 pF

1.1 µA

2.8 V

1 + 0.2

0.15 + 0.05

10.000 nF

1 pF

1.1 µA

2.8 V

1 + 0.1

0.15 + 0.01

100.00 nF

10 pF

10 µA

3 V

0.4 + 0.1

0.01 + 0.01

1.0000 µF

0.1 nF

100 µA

3 V

0.4 + 0.1

0.01 + 0.01

10.000 µF

1 nF

100 µA

3 V

0.4 + 0.1

0.01 + 0.01

100.00 µF

10 nF

1 mA

3 V

0.4 + 0.1

0.01 + 0.01

1000.0 µF

0.1 µF

10 mA

3 V

0.5 + 0.1

0.01 + 0.01

Diode

Voltage

Resolution

Bias Level (Selectable)

Accuracy ±(ppm of reading + ppm of range)

90 Day

T

1 Year

T

2 Year

T

Temperature

10.000000 V

1 µV

10 µA / 100 µA / 1 mA

20 + 5

30 + 5

45 + 5

2.5 + 1

Digitize Voltage

Accuracy (Input Impedance AUTO)

Accuracy ±(ppm of reading + ppm of range)

90 Day

T

1 Year

T

2 Year

T

Temperature

100.000 mV

1 µV

>10 G

Ω or 10 MΩ ±1%

210 + 100

220 + 100

230 + 100

15 + 20

1.00000 V

10 µV

>10 G

Ω or 10 MΩ ±1%

110 + 75

120 + 75

130 + 75

15 + 20

10.0000 V

0.1 mV

>10 G

Ω or 10 MΩ ±1%

110 + 75

120 + 75

130 + 75

10 + 20

1 mV

10 M

Ω ±1%

110 + 75

120 + 75

130 + 75

15 + 20

10 mV

10 M

Ω ±1%

110 + 75

120 + 75

130 + 75

10 + 20

NOTES

51. 20% overrange on all ranges.

52. Charging current values are typical, guaranteed by design.

53. Discharge current limited to <13 mA.

54. For DC coupling, 20% overrange for 100 mV to 100 V. For AC coupling, 500% overrange 100 mV to 100 V. 1% for 1000 V range DC and AC coupling.

55. Accuracy with sample rate 1k per second, aperture auto, and 100 reading buffer average.

56. Power up default is 4½ digits.

57. User-selectable.

58. Add per degree from T

59. For 100 V range, input impedance auto and without ACAL, add 100ppm of range additional uncertainty and 15 ppm/°C additional uncertainty for “of range” temperature coefficient for

operation outside of T

60. For signal levels greater than 500 V, add 0.02 ppm/V to the ppm of the readings specification for measurements exceeding 500 V.
