Temperature

4-Wire RTD or 3-Wire RTD

Types: 100

Ω platinum PT100, D100, F100, PT385, PT3916; or user-configurable 0 Ω to 10 kΩ.

Type

Range

Resolution

Accuracy ±°C

2 Year, T

4-Wire RTD

–200 to 850 °C

0.01 °C

0.06 °C

0.003 °C/°C

–200 to 850 °C

0.01 °C

0.75 °C

0.003 °C/°C

Thermistor

Types: 2.252 k

Ω, 5 kΩ, and 10 kΩ.

Type

Range

Resolution

Accuracy ±°C

2 Year, T

Thermistor

–80 to +150 °C

0.01 °C

0.08 °C

0.002 °C/°C

Thermocouple

Types: B, E, J, K, N, R, S, T

Accuracy ±°C

Type

Range

Resolution

2 Year, T

48

Simulated

Reference Junction

Temperature

B

350 to +1820 °C

0.1 °C

0.6 °C

0.03 °C/°C

E

−200 to +1000 °C

0.001 °C

0.2 °C

0.03 °C/°C

J

−200 to +760 °C

0.001 °C

0.2 °C

0.03 °C/°C

K

−200 to +1372 °C

0.001 °C

0.2 °C

0.03 °C/°C

N

−200 to +1300 °C

0.001 °C

0.2 °C

0.03 °C/°C

R

0 to +1768 °C

0.1 °C

0.6 °C

0.03 °C/°C

S

0 to +1768 °C

0.1 °C

0.6 °C

0.03 °C/°C

T

−100 to +400 °C

0.001 °C

0.2 °C

0.03 °C/°C

Continuity

Resolution

Test Current

Open Circuit Voltage

Accuracy ±(ppm of reading + ppm of range)

2 Year, T

1.0000 k

Ω

100 m

Ω

1 mA

14.0 V

100 + 100

2.5 + 1

Continuity Characteristics

Continuity High Limit

User-selectable; default 10

Ω.

NOTES

46. Add per degree from T

47. For 3-wire RTD, accuracy is for <0.1

Ω lead resistance mismatch for input HI and LO. Add 0.25°C/0.1 Ω of HI-LO lead resistance mismatch.

48. Exclusive of cold-junction errors.

49. Specifications exclude lead resistance.

50. Add per degree from T
