TEK.COM
3
DMM 7510 7½-Digit Graphical Sampling Multimeter
Designed for Higher
Testing Productivity
In addition to its advanced
touchscreen, the DMM7510’s front
panel offers a variety of features that
enhance its speed, user-friendliness,
and learnability, including a USB 2.0
memory I/O port, a HELP key, a rotary
navigation/control knob, and front/
rear input selector button. All front-
panel buttons are backlit to enhance
visibility.
The rear panel of the DMM7510
provides connections and controls
that simplify configuring multi-
instrument test solutions, including
input connectors, remote control
interfaces (GPIB, USB 2.0 and LXI/
Ethernet), a D-sub 9-pin digital I/O
port (for internal/external trigger
signals and handler control), and TSP-
Link® jacks for connecting to other
TSP-enabled instruments.
Easily accessible
current fuses
Measure Complete and External Trigger
(8503 BNC Accessory Available)
GPIB interface
Six user-defined
digital I/Os
USB 2.0
interface
LAN/LXI interface
Online HELP is just a
button press away
Store test results
and screen images
quickly via the USB 2.0
memory port
Lower swipe screen speeds
access to often-used features
Five-inch touchscreen displays more
information simultaneously
Rotary control knob offers an
alternative to touchscreen navigation
Front/rear input selector
DMM7510 Measurement Capabilities
DC Voltage
AC Voltage
DC Current
AC Current
Resistance (2-wire)
Resistance (4-wire)
Dry Circuit Resistance
Capacitance
Period
Frequency
Digitize Voltage
Digitize Current
10nV
100nV
Logarithmic Scale
Linear Scale
1pA
1nA
100n
1µ
0.1pF
–200°C
–80°C
–200°C
–200°C
1820°C
150°C
850°C
850°C
2µs
3Hz
1µV
0.1nA
1010V
707VRMS
10.1A
10.1A
1.2G
2.4k
1µ
1.2G
1.2mF
330ms
500kHz
1010V
10.1A
1f
1p
1n
1µ
1m
1
1k
1M
1G
Thermocouple
Thermistor
3-Wire RTD
4-Wire RTD
–500°
0°
500°
1000°
1500°
2000°
