TMOD (0x89) - Timer / Counter 0 and 1 Mode register

Bit

Name

R/W

Reset value

Description

GATE1

R/W

Timer / Counter 1 gate control

0 : Timer / Counter 1 will clock only when

TCON.TR1 is set.

1 : Timer / Counter 1 will clock only when

TCON.TR1 is set

and the

INT0 input is high.

C/ T 1

R/W

Counter / Timer select for Counter / Timer 1

0 : Timer 1 is clocked by the system clock divided by 4 or 12,

depending on the state of

CKCON.T1M (see page 55)

1 : Timer 1 is clocked by the

T1 pin.

M1.1

R/W

M1.0

R/W

Timer / Counter 1 mode select bits

00 : 13-bit counter

01 : 16-bit counter

10 : 8-bit counter with auto-reload

11 : Timer 1 off

GATE0

R/W

Timer / Counter 0 gate control

0 : Timer / Counter 0 will clock only when

TCON.TR0 is set.

1 : Timer / Counter 0 will clock only when

TCON.TR0 is set

and the

INT0 input is high.

C/ T 0

R/W

Counter / Timer select for Counter / Timer 0

0 : Timer 0 is clocked by the system clock divided by 4 or 12,

depending on the state of

CKCON.T0M (see page 55)

1 : Timer 0 is clocked by the

T0 pin.

M0.1

R/W

M0.0

R/W

Timer / Counter 0 mode select bits

00 : 13-bit counter

01 : 16-bit counter

10 : 8-bit counter with auto-reload

11 : Two 8-bit counters
