CC1010-RTY1 datasheet(27/152 Pages) TI

27 / 152 page

CC1010

SWRS047

Page 27 of 152

Mnemonic

Description

Branching

ACALL addr 11

Absolute call to subroutine

11-F1

LCALL addr 16

Long call to subroutine

RET

Return from subroutine

RETI

Return from interrupt

AJMP addr 11

Absolute jump unconditional

01-E1

LJMP addr 16

Long jump unconditional

SJMP rel

Short jump (relative address)

JC rel

Jump on carry = 1

JNC rel

Jump on carry = 0

JB bit, rel

Jump on direct bit = 1

JNB bit, rel

Jump on direct bit = 0

JBC bit, rel

Jump on direct bit = 1 and clear

JMP @A+DPTR

Jump indirect relative DPTR

JZ rel

Jump on accumulator = 0

JNZ rel

Jump on accumulator /= 0

CJNE A, direct,

rel

Compare A and direct, jump

relative if not equal

CJNE A, #d, rel

Compare A and immediate, jump

relative if not equal

CJNE Rn, #d, rel

Compare reg and immediate,

jump relative if not equal

B8-

CJNE @Ri, #d, rel

Compare ind and immediate, jump

relative if not equal

B6-

DJNZ Rn, rel

Decrement register, jump relative

if not zero

D8-

DJNZ direct, rel

Decrement direct byte, jump

relative if not zero

Misc.

NOP

No operation

TRAP

Set

EICON.FDIF = 1, used for

breakpoints

Table 12. Instruction Set Summary
