CC1010

SWRS047

Page 17 of 152

Pins P3.0 and P3.1 can be configured to

become the RXD0 and TXD0 pin,

respectively, of UART 0.

Pins P3.2 and P3.3 are connected to the

external interrupt inputs INT0 and INT1,

respectively, and can cause interrupts if

the corresponding interrupt enable flags

are set in register IE. The interrupts inputs

can be configured to be either level-

sensitive or edge-sensitive.

Pins P3.4 and P3.5 can be configured to

become the pulse width modulator (PWM)

outputs of Timer/PWM 2 and Timer/PWM

respectively.

When

pulse

width

modulation is enabled the corresponding

bits in P3DIR and P3 are overridden.
