CC1010
SWRS047
Page 109 of 152
FREQ_0B (0xCD) - Frequency B, Control Register 0
Bit
Name
R/W
Reset value
Description
7:0
FREQ_B(7:0)
R/W
0x4E
8 LSB of frequency control word B.
FSEP1 (0xEB) - Frequency Separation Control Register 1
Bit
Name
R/W
Reset value
Description
7:3
-
R0
0
Reserved, read as 0
2:0
FSEP(10:8)
R/W
0x00
3 MSB of the frequency separation control word
FSEP
FSEP0 (0xEA) - Frequency Separation Control Register 0
Bit
Name
R/W
Reset value
Description
7:0
FSEP(7:0)
R/W
0x59
8 LSB of the frequency separation control word
FSEP
PLL (0xE3) - PLL Control Register
Bit
Name
R/W
Reset value
Description
7:3
REFDIV(4:0)
R/W
0x02
Reference divider setting. The main crystal oscillator
frequency is divided by
REFDIV to create the RF
reference frequency fref. Valid
REFDIV settings are 2
through 24, as described above.
2
ALARM_
DISABLE
R/W
0
Disable / Enable the generation of the
ALARM_H and
ALARM_L bits
0 : Alarm function enabled
1 : Alarm function disabled
1
ALARM_H
R
None
Status bit for tuning voltage out of range (too close to
VDD)
The PLL should be re-calibrated if this bit is set
0
ALARM_L
R
None
Status bit for tuning voltage out of range (too close to
GND)
The PLL should be re-calibrated if this bit is set
