144 / 152 page  CC1010 SWRS047 Page 144 of 152 Addr Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reset Page 0xE6 PRESCALE PRE_SWING1 PRE_SWING0 PRE_CURRENT1 PRE_CURRENT0 IF_INPUT IF_FRONT PRESCALE.1 PRESCALE.0 00000000 129 0xE7 RESERVED RESERVED.7 RESERVED.6 RESERVED.5 RESERVED.4 RESERVED.3 RESERVED.2 RESERVED.1 RESERVED.0 00000000 45 0xE8 EIE - - - RTCIE ET3 ADIE ET2 RFIE 11100000 29 0xE9 FSDELAY FSDELAY7 FSDELAY6 FSDELAY5 FSDELAY4 FSDELAY3 FSDELAY2 FSDELAY1 FSDELAY0 00101111 129 0xEA FSEP0 FSEP7 FSEP6 FSEP5 FSEP4 FSEP3 FSEP2 FSEP1 FSEP0 01011001 109 0xEB FSEP1 - - - - - FSEP10 FSEP9 FSEP8 00000000 109 0xEC FSCTRL - - - EXT_FILTER DITHER1 DITHER0 SHAPE FS_RESET_N 00000001 130 0xED RTCON RTEN RT6 RT5 RT4 RT3 RT2 RT1 RT0 00000000 65 0xEE FREND - - LNA_BUF_CUR LNA_CURRENT1 LNA_CURRENT0 IF_EXTERNAL RSSI - 00000000 119 0xEF TESTMUX - - - - TESTSEL3 TESTSEL2 TESTSEL1 TESTSEL0 00000000 130 0xF0 B B.7 B.6 B.5 B.4 B.3 B.2 B.1 B.0 00000000 23 0xF1 FSHAPE7 FSHAPE7.7 FSHAPE7.6 FSHAPE7.5 FSHAPE7.4 FSHAPE7.3 FSHAPE7.2 FSHAPE7.1 FSHAPE7.0 00011100 129 0xF2 FSHAPE6 FSHAPE6.7 FSHAPE6.6 FSHAPE6.5 FSHAPE6.4 FSHAPE6.3 FSHAPE6.2 FSHAPE6.1 FSHAPE6.0 00010110 129 0xF3 FSHAPE5 FSHAPE5.7 FSHAPE5.6 FSHAPE5.5 FSHAPE5.4 FSHAPE5.3 FSHAPE5.2 FSHAPE5.1 FSHAPE5.0 00010000 129 0xF4 FSHAPE4 FSHAPE4.7 FSHAPE4.6 FSHAPE4.5 FSHAPE4.4 FSHAPE4.3 FSHAPE4.2 FSHAPE4.1 FSHAPE4.0 00001010 129 0xF5 FSHAPE3 FSHAPE3.7 FSHAPE3.6 FSHAPE3.5 FSHAPE3.4 FSHAPE3.3 FSHAPE3.2 FSHAPE3.1 FSHAPE3.0 00000110 129 0xF6 FSHAPE2 FSHAPE2.7 FSHAPE2.6 FSHAPE2.5 FSHAPE2.4 FSHAPE2.3 FSHAPE2.2 FSHAPE2.1 FSHAPE2.0 00000011 129 0xF7 FSHAPE1 FSHAPE1.7 FSHAPE1.6 FSHAPE1.5 FSHAPE1.4 FSHAPE1.3 FSHAPE1.2 FSHAPE1.1 FSHAPE1.0 00000001 129 0xF8 EIP - - - PRTC PT3 PAD PT2 PRF 11100000 31 0xF9 TEST0 - - - - VCO_ARRAY3 VCO_ARRAY2 VCO_ARRAY1 VCO_ARRAY0 0000xxxx 115 0xFA TEST1 - - - - CAL_DAC3 CAL_DAC2 CAL_DAC1 CAL_DAC0 0000xxxx 115 0xFB TEST2 - - - CHP_CURRENT4 CHP_CURRENT3 CHP_CURRENT2 CHP_CURRENT1 CHP_CURRENT0 000xxxxx 115 0xFC TEST3 - - - BREAK_LOOP CAL_DAC_ OPEN3 CAL_DAC_ OPEN2 CAL_DAC_ OPEN1 CAL_DAC_ OPEN0 00000100 115 0xFD TEST4 - - L2KIO0.5 L2KIO0.4 L2KIO0.3 L2KIO0.2 L2KIO0.1 L2KIO0.0 00100101 115 0xFE TEST5 - - CHP_DISABLE VCO_OVERRIDE VCO_AO3 VCO_AO2 VCO_AO1 VCO_AO0 00001000 115 0xFF TEST6 LOOPFILTER_ TP1 LOOPFILTER_ TP2 CHP_OVERRIDE CHP_CO4 CHP_CO3 CHP_CO2 CHP_CO1 CHP_CO0 00010000 114 Table 41. SFR Summary (sorted by address) |
|
