GPMC_FCLK

GPMC_CLK

GPMC_CSn[i]

GPMC_BE0n_CLE

GPMC_BE1n

GPMC_ADVn_ALE

GPMC_OEn_REn

GPMC_WAIT[j]

Address (MSB)

Valid

Address (LSB)

Data IN

FA0

FA9

FA10

FA3

FA13

FA29

FA1

FA37

FA12

FA4

FA10

FA0

FA5

GPMC_A[27:17]

GPMC_AD[15:0]

GPMC_10

In GPMC_CSn[i], i is equal to 0, 1, 2 or 3. In GPMC_WAIT[j], j is equal to 0 or 1.

FA5 parameter illustrates amount of time required to internally sample input data. It is expressed in number of GPMC functional clock

cycles. From start of read cycle and after FA5 functional clock cycles, input data will be internally sampled by active functional clock

edge. FA5 value must be stored inside AccessTime register bits field.

GPMC_FCLK is an internal clock (GPMC functional clock) not provided externally.

Figure 6-56. GPMC and Multiplexed NOR Flash — Asynchronous Read — Single Word

www.ti.com

TDA4VEN-Q1, TDA4AEN-Q1

SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024

Submit Document Feedback

157

Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1
