PACDN042/43/44/45/46

Rev. 4 | Page 5 of 24 | www.onsemi.com

STANDARD OPERATING CONDITIONS

PARAMETER

RATING

UNITS

Operating Temperature

-40 to +85

°C

ELECTRICAL OPERATING CHARACTERISTICS

SYMBOL PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

C

Capacitance

T

30

pF

I

5.5

V

V

RSO

Reverse Stand-off Voltage

I

6.1

V

I

LEAK

Leakage Current

V

1

100

nA

V

SIG

Small Signal Clamp Voltage

Positive Clamp

Negative Clamp

I = 10mA, T

I = -10mA, T

6.2

-0.4

6.8

-0.8

8

-1.2

V

V

V

ESD

ESD Withstand Voltage

Human Body Model, MIL-STD-883,

Method 3015

Contact Discharge per IEC 61000-4-2

standard

Note 1

Note 1

+30

+20

kV

kV

R

D

Diode Dynamic Resistance

Forward Conduction

Reverse Conduction

1.0

1.4

Ω

Ω

Note 1: ESD voltage applied between channel pins & ground, one pin at a time; all other channel pins open; all GND pins

grounded.
