PACDN042/43/44/45/46
Rev. 4 | Page 8 of 24 | www.onsemi.com
SOT23-3 Tape and Reel Specifications
PART NUMBER
PACKAGE SIZE
(mm)
POCKET SIZE (mm)
B
0 X A0 X K0
TAPE WIDTH
W
REEL
DIAMETER
QTY PER
REEL
P
0
P
1
PACDN042Y3R
2.92 X 2.37 X 1.01
2.77 X 3.15 X 1.22
8mm
178mm (7")
3000
4mm
4mm
