190 / 236 page  Table 6-100 presents timing conditions for MMC1. Table 6-100. MMC1/MMC2 Timing Conditions PARAMETER MIN MAX UNIT Input Conditions SRI Input slew rate Default Speed High Speed 0.69 2.06 V/ns UHS–I SDR12 UHS–I SDR25 0.34 1.34 V/ns UHS–I DDR50 1 2 V/ns Output Conditions CL Output load capacitance All modes 1 10 pF PCB Connectivity Requirements td(Trace Delay) Propagation delay of each trace UHS–I DDR50 239 1134 ps All other modes 126 1386 ps td(Trace Mismatch Delay) Propagation delay mismatch across all traces High Speed UHS–I SDR104 8 ps UHS–I DDR50 20 ps All other modes 100 ps TDA4VEN-Q1, TDA4AEN-Q1 SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024 www.ti.com 190 Submit Document Feedback Copyright © 2024 Texas Instruments Incorporated Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1 |
|
