187 / 236 page  6.9.5.18.1.9 UHS–I DDR50 Mode Table 6-97 and Figure 6-82 present switching characteristics for MMC0 – UHS-I DDR50 Mode. Table 6-97. Switching Characteristics for MMC0 – UHS-I DDR50 Mode see Figure 6-82 NO. PARAMETER MIN MAX UNIT fop(clk) Operating frequency, MMC0_CLK 50 MHz DDR505 tc(clk) Cycle time, MMC0_CLK 20 ns DDR506 tw(clkH) Pulse duration, MMC0_CLK high 9.2 ns DDR507 tw(clkL) Pulse duration, MMC0_CLK low 9.2 ns DDR508 td(clk-cmdV) Delay time, MMC0_CLK rising edge to MMC0_CMD transition 1.12 6.43 ns DDR509 td(clk-dV) Delay time, MMC0_CLK transition to MMC0_DAT[3:0] transition 1.12 6.43 ns MMC[x] CLK _ MMC[x] CMD _ MMC[x] DAT3 _ [ :0] DDR508 DDR509 DDR509 DDR505 DDR506 DDR507 Figure 6-82. MMC0 – UHS-I DDR50 – Transmit Mode www.ti.com TDA4VEN-Q1, TDA4AEN-Q1 SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024 Copyright © 2024 Texas Instruments Incorporated Submit Document Feedback 187 Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1 |
|
