186 / 236 page  6.9.5.18.1.8 UHS–I SDR50 Mode Table 6-96 and Figure 6-81 presents switching characteristics for MMC0 – UHS-I SDR50 Mode. Table 6-96. Switching Characteristics for MMC0 – UHS-I SDR50 Mode see Figure 6-81 NO. PARAMETER MIN MAX UNIT fop(clk) Operating frequency, MMC0_CLK 100 MHz SDR505 tc(clk) Cycle time, MMC0_CLK 10 ns SDR506 tw(clkH) Pulse duration, MMC0_CLK high 4.45 ns SDR507 tw(clkL) Pulse duration, MMC0_CLK low 4.45 ns SDR508 td(clkL-cmdV) Delay time, MMC0_CLK rising edge to MMC0_CMD transition 1.2 6.35 ns SDR509 td(clkL-dV) Delay time, MMC0_CLK rising edge to MMC0_DAT[3:0] transition 1.2 6.35 ns MMC[ ]_CLK x MMC CMD [ ]_ x MMC DAT [x]_ [3:0] SDR505 SDR507 SDR506 SDR508 SDR509 SDR508 SDR509 Figure 6-81. MMC0 – UHS-I SDR50 – Transmit Mode TDA4VEN-Q1, TDA4AEN-Q1 SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024 www.ti.com 186 Submit Document Feedback Copyright © 2024 Texas Instruments Incorporated Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1 |
|
