ISL85415
4. Typical Performance Curves
FN8373 Rev.5.01
Page 18 of 30
Jun.4.20
Figure 51. Overcurrent Protection, PWM
Figure 52. Overcurrent Protection Hiccup, PWM
Figure 53. SYNC AT 500mA Load, PWM
Figure 54. Negative Current Limit, PWM
Figure 55. Negative Current Limit Recovery, PWM
Figure 56. Over-Temperature Protection, PWM
VIN = 24V, VOUT = 3.3V, fSW = 800kHz, TA = +25°C. (Continued)
VOUT 2V/Div
IL 500mA/Div
PG 2V/Div
20µs/Div
PHASE 20V/Div
50ms/Div
VOUT 2V/Div
IL 1A/Div
PG 2V/Div
PHASE 20V/Div
SYNC 2V/Div
200ns/Div
PHASE 20V/Div
VOUT 5V/Div
IL 0.5A/Div
PG 2V/Div
10µs/Div
PHASE 20V/Div
VOUT 5V/Div
PG 2V/Div
200µs/Div
IL 0.5A/Div
PHASE 20V/Div
VOUT 2V/Div
PG 2V/Div
500µs/Div
