4 / 141 page  Data Sheet ADMV1455 SPECIFICATIONS analog.com Rev. 0 | 4 of 141 TC = 25°C, VDD_BB = 2.5V, and all other supplies = 1.8V, unless otherwise noted. Table 1. Specifications Parameter Test Conditions/Comments Min Typ Max Unit FREQUENCY RANGES RF Input (fRF) Low Band Signal Chain 17.7 34 GHz High Band Signal Chain 30 55 GHz LO Input (fLO) 8.85 27.5 GHz 2× LO Multiplier (2× fLO) 17.7 55 GHz IF Single-Ended Output 2 12 GHz Baseband I/Q Differential Output DC 8 GHz LO AMPLITUDE RANGE fLO < 25GHz −7 −3 dBm fLO ≥ 25GHz −3 0 dBm OPERATING TEMPERATURE RANGE −40 +95 °C IMAGE REJECTION CONTROL LO Phase Adjustment ±20 Degrees LO Phase Step 0.6 Degrees IF Amplitude Step Size 0.1 dB BASEBAND OUTPUT COMMON-MODE VOLTAGE (VOCM) Internally generated, digitally controlled VDD_BB = 1.8V 0.8 1.1 V VDD_BB = 2.5V 0.8 1.5 V POWER DETECTOR PERFORMANCE Input Range Power at RF_IN and output measured digitally via the on-chip analog-to-digital converter (ADC) −40 −17 dBm RETURN LOSS RF_IN Input 50Ω single-ended Low Band 17GHz to 34GHz −10 dB High Band 30GHz to 55GHz −8 dB DSA_IN Input and DSA1 = 0dB 50Ω single-ended Low Band 17GHz to 50GHz −14 dB High Band 50GHz to 55GHz −6 dB DSA_IN Input and DSA1 = 15dB 50Ω single-ended Low Band 17GHz to 50GHz −11 dB High Band 50GHz to 55GHz −6 dB DSA_OUT Output and DSA1 = 0dB 50Ω single-ended Low Band 17GHz to 50GHz −12 dB High Band 50GHz to 55GHz −6 dB DSA_OUT Output and DSA1 = 15dB 50Ω single-ended Low Band 17GHz to 50GHz −15 dB High Band 50GHz to 55GHz −8 dB LO Input 50Ω single-ended −8 dB IF Output 50Ω single-ended dB 2GHz to 6GHz −7 dB 4GHz to 8GHz −9 dB 6GHz to 10GHz −9 dB 8GHz to 12GHz −15 dB |
|
