ADMV1455BBCZ-R7 Scheda tecnica(PDF) 95 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADMV1455BBCZ-R7 Scheda tecnica(HTML) 95 Page - Analog Devices |
|
|
95 / 141 page  Data Sheet ADMV1455 REGISTER DETAILS analog.com Rev. 0 | 95 of 141 Address: 0x005, Reset: 0x00, Name: REG0005 Figure 180. Table 30. Bit Descriptions for REG0005 Bits Bit Name Description Reset Access [7:0] PRODUCT_ID[15:8] Product ID. 0x0 R Address: 0x00A, Reset: 0x00, Name: REG000A Figure 181. Table 31. Bit Descriptions for REG000A Bits Bit Name Description Reset Access [7:0] SCRATCH_PAD Scratch Pad. 0x0 R/W Address: 0x040, Reset: 0x00, Name: REG0040 Figure 182. Table 32. Bit Descriptions for REG0040 Bits Bit Name Description Reset Access [7:0] ADC_TEMP_SENSOR_READBACK ADC Temperature Sensor Readback. Updated in automatic mode only. 0x0 R Address: 0x041, Reset: 0x00, Name: REG0041 Figure 183. Table 33. Bit Descriptions for REG0041 Bits Bit Name Description Reset Access [7:0] ADC_DETECTOR_READBACK ADC Power Detector Readback. 0x0 R Address: 0x043, Reset: 0x00, Name: REG0043 Figure 184. |
|
