2 / 141 page ![]() Data Sheet ADMV1455 TABLE OF CONTENTS analog.com Rev. 0 | 2 of 141 Features................................................................ 1 Applications........................................................... 1 General Description...............................................1 Functional Block Diagram......................................3 Specifications........................................................ 4 IF Mode.............................................................. 6 I/Q Baseband Mode........................................... 8 Timing Specifications....................................... 10 Absolute Maximum Ratings................................. 11 Thermal Resistance......................................... 13 Electrostatic Discharge (ESD) Ratings.............14 ESD Caution.....................................................14 Pin Configuration and Function Descriptions...... 15 Typical Performance Characteristics................... 19 IF Mode, RF_IN, High Band............................. 19 Return Loss......................................................30 LO Leakage......................................................32 IF Mode, RF_IN, Low Band..............................35 IF Mode, DSA_IN, Low Band........................... 42 IF Mode, DSA_IN, High Band.......................... 47 Baseband Mode, DSA_IN, Low Band.............. 52 Baseband Mode, DSA_IN, High Band............. 57 Theory of Operation.............................................65 Chip Overview.................................................. 65 Power-Up and Initialization Sequence............. 65 Power-Down Sequence....................................65 SPI....................................................................66 Timing Diagrams Overview.............................. 67 Nonvolatile Memory..........................................70 Digital Overview............................................... 70 Synchronous LOAD Feature............................ 71 Filter LUT..........................................................71 Gain LUT..........................................................73 General-Purpose Outputs................................ 74 RF Connections................................................74 LO Signal Chain .............................................. 74 LO Tunable Filters............................................75 DSA1................................................................76 RF Signal Chains............................................. 76 DSA2................................................................77 DSA3................................................................77 RF Tunable LPFs............................................. 77 RF Tunable HPF.............................................. 77 Mixer Overview.................................................78 Mixer Sideband Selection.................................78 I/Q Baseband Signal Chains............................ 78 I/Q Baseband Gain Selection...........................79 I/Q Baseband Common-Mode Voltage (VOCM)............................................................ 79 I/Q Baseband DC Offsets.................................79 IF Signal Chain.................................................79 Image Rejection Optimization.......................... 80 IF Tunable BPF................................................ 81 DSA4................................................................82 DSA5................................................................82 Total Gain Control.............................................82 RF Gain Policy................................................. 82 Automatic ADC Configuration.......................... 82 Power Detector.................................................83 Temperature Sensor.........................................83 Overload Protection..........................................84 Applications Information...................................... 85 Recommended Settings...................................85 Recommended PCB Layout.............................86 Evaluation Board Information...........................86 Register Summary...............................................87 Register Details................................................... 94 Register 0x000 to Register 0x0A1....................94 Register 0x101 to Register 0x194.................. 100 Register 0x200 to Register 0x2B0..................108 Register 0x600 to Register 0x80C................. 125 Register 0x900 to Register 0xE03..................133 Outline Dimensions........................................... 141 Ordering Guide...............................................141 REVISION HISTORY 12/2025—Revision 0: Initial Version |
|
