FT93x Datasheet Embedded Microcontroller Datasheet

Version 1.5

Document Reference No.: BRT_000051

Clearance No.: BRT#049

No.

Name

Type

Description

SPIM_SS0/GPIO30

I/O

GPIO30 input/output. (By default is GPIO input,

internal pull-low)

Slave select 0 output for SPI master.

SPIM_SS1/GPIO31

I/O

GPIO31 input/output. (By default is GPIO input,

internal pull-low)

Slave select 1 output for SPI master.

SPIM_SS2/GPIO32

I/O

GPIO32 input/output. (By default is GPIO input,

internal pull-low)

Slave select 2 output for SPI master.

SPIM_SS3/GPIO33

I/O

GPIO33 input/output. (By default is GPIO input,

internal pull-low)

Slave select 3 output for SPI master.

SPIM_CLK/SPIS_CLK/

GPIO34

I/O

GPIO34 input/output. (By default is GPIO input,

internal pull-low)

Serial clock output for SPI master.

Serial clock input for SPI slave.

SPIM_MISO/SPIS_MISO/

GPIO35

I/O

GPIO35 input/output. (By default is GPIO input,

internal pull-low)

Master in slave out for SPI master.

Master in slave out for SPI slave.

SPIM_MOSI/SPIS_MOSI/

GPIO36

I/O

GPIO36 input/output. (By default is GPIO input,

internal pull-low)

Master out slave in for SPI master.

Master out slave in for SPI slave.

SPIM_IO2/SPIS_SS/

GPIO37

I/O

GPIO37 input/output. (By default is GPIO input,

internal pull-low)

Data line 2 input/output for SPI master quad mode.

Slave select input for SPI slave.

SPIM_IO3/RTC_REF/GPIO38

I/O

GPIO38 input/output. (By default is GPIO input,

internal pull-low)

Data line 3 input/output for SPI master quad mode.

Reference clock for RTC calibration.

VCCIO3V3

+3.3V supply voltage.

This is the supply voltage for all the I/O ports.

Connect a 0.1uF decoupling capacitor.

GND

Ground.

VCC1V2

+1.2V core voltage.
