Copyright © Bridgetek Pte Ltd
41
FT93x Datasheet Embedded Microcontroller Datasheet
Version 1.5
Document Reference No.: BRT_000051
Clearance No.: BRT#049
5
Device Characteristics and Ratings
5.1
Absolute Maximum Ratings
The absolute maximum ratings for the FT93x series devices are as follows. These are in accordance with
the Absolute Maximum Rating System (IEC 60134). Exceeding these may cause permanent damage to
the device.
Parameter
Value
Unit
Storage Temperature
-65 to +150
°C
Floor Life (Out of Bag) At Factory Ambient
(30°C / 60% Relative Humidity)
168 Hours
(IPC/JEDEC J-STD-033A MSL Level 3
Compliant)*
Hours
Ambient Temperature (Power Applied)
-40 to +85
°C
VCC3V3 Supply Voltage
-0.5 to +4.6
V
DC Input Voltage:
USB Device D_DP and D_DM
-0.5 to +5
V
DC Input Voltage:
5V tolerant I/O cells
-0.5 to +5.8
V
Others (ADC, DAC) – 3V I/O cells
-0.5 to VCC3V3+0.5
V
Table 5-1 Absolute Maximum Ratings
* If devices are stored out of the packaging beyond this time limit, the devices should be baked before
use. The devices should be ramped up to a temperature of +125°C and baked for up to 17 hours.
