FT93x Datasheet Embedded Microcontroller Datasheet

Version 1.5

Document Reference No.: BRT_000051

Clearance No.: BRT#049

Typical Applications



Companion with FT81x for multi-screen

display



USB to multiple interface bridging (up to 15

end points)



Motor drive and application control



E-meter



DAQ System Industrial automation



Medical appliances



Instrumentation

1.1

Part Numbers

Part Number

Package

FT930Q-X

68 Pin QFN, pitch 0.4mm, body 8mm x 8mm x 0.85mm, supports ADC/DAC,

SD-Card, and RTC features.

FT931Q-X

56 Pin QFN, pitch 0.5mm, body 8mm x 8mm x 0.85mm, supports ADC/DAC,

SD-Card, and RTC features.

FT932Q-X

48 Pin QFN, pitch 0.5mm, body 7mm x 7mm x 0.85mm, supports ADC/DAC

and SD-Card features, no RTC feature.

FT933Q-X

48 Pin QFN, pitch 0.5mm, body 7mm x 7mm x 0.85mm, supports ADC feature,

no SD-Card and no RTC features.

Table 1-1 FT93x Series Part Numbers

Packaging codes for X:

Packaging Code

Part

Packing

Qty

-R

FT93x

Tape and Reel

3000

-T

FT930

FT931

Tray Packing

348

FT932

FT933

Tray Packing

260
