M27500 Cables—types RC and RE (M22759/11, /12 components)

M27500 - 8 RC1S06

Component wire AWG

Component wire type

RC: MIL-W-22759/11

RE: MIL-W-22759/12

Jacket material—05: Clear extruded FEP

06: White PTFE tape

09: White extruded FEP

Number of component wires

Shield material—

N: Nickel-plated copper

S: Silver-plated copper

M27500 RC and RE cables

are shielded and jacketed

cables with PTFE tape or extruded FEP jackets,

incorporating MIL-W-22759/11 or /12 wires.

These component wires have extruded PTFE insula-

tion and silver- or nickel-plated copper conductors.

PTFE tape jackets are available with our unique

Seamless Wrap PTFE tape (see page 87 for details).

Performance:

Voltage rating:

600V.

Temperature ratings:

Cables with /11 component wires and either jacket: -55 to 200˚ C.

Cables with /12 component wires and PTFE jacket: -55 to 260˚ C.

Cables with /12 component wires and FEP jacket: -55 to 200˚ C.

See page 40 for component wire dimensions.

Construction Details

Component wire conductor:

/11 component wires: Silver-plated copper;

/12 component wires: Nickel-plated copper.

Component wire insulation:

Extruded PTFE.

Shield:

Nickel- or silver-plated copper braid, 85% coverage.

Jacket:

Extruded FEP or PTFE tape.

Colors:

Color coded to M27500 (see page 67).

Certiﬁcations also available to NEMA WC27500.

Dimensions and Weight—1 Conductor Cables

Dimensions and Weight—2 Conductor Cables

Dimensions and Weight—3 Conductor Cables*

Dimensions and Weight—4 Conductor Cables

Dimensions in inches (mm). Weights in pounds/1000 feet (Kg/1000 M). All values are nominal. *Using factors from a circumscribed circle per M27500.

Component Wire

Shield

Jacket

Weight

AWG (Stranding)

Diameter

8 (133/29)

.515 (13.1)

.551 (14.0)

340 (506)

(37/26)

.355 (9.02)

.391 (9.93)

179 (266)

(19/25)

.288 (7.30)

.324 (8.22)

120 (179)

(19/27)

.233 (5.92)

.257 (6.53)

78.6 (117)

(19/29)

.197 (5.00)

.221 (5.61)

52.6 (78.3)

(19/30)

.180 (4.57)

.204 (5.18)

46.5 (69.2)

(19/32)

.156 (3.96)

.184 (4.67)

34.4 (51.2)

(19/34)

.134 (3.41)

.156 (3.96)

23.9 (35.6)

(19/36)

.120 (3.04)

.142 (3.61)

19.0 (28.3)

(19/38)

.108 (2.73)

.130 (3.30)

15.4 (22.9)

(7/36)

.096 (2.43)

.118 (3.00)

12.3 (18.3)

Component Wire

Shield

Jacket

Weight

AWG (Stranding)

Diameter

8 (133/29)

.462 (11.7)

.498 (12.7)

248 (369)

(37/26)

.319 (8.10)

.356 (9.04)

138 (205)

(19/25)

.255 (6.47)

.280 (7.10)

90.9 (135)

(19/27)

.210 (5.32)

.234 (5.93)

61.7 (91.8)

(19/29)

.177 (4.50)

.201 (5.11)

43.7 (65.0)

(19/30)

.162 (4.12)

.186 (4.73)

37.0 (55.1)

(19/32)

.141 (3.57)

.163 (4.14)

26.2 (39.0)

(19/34)

.121 (3.08)

.143 (3.63)

19.3 (28.7)

(19/36)

.108 (2.75)

.132 (3.36)

15.5 (23.1)

(19/38)

.098 (2.48)

.122 (3.09)

12.9 (19.2)

(7/36)

.087 (2.21)

.109 (2.77)

10.2 (15.2)

Component Wire

Shield

Jacket

Weight

AWG (Stranding)

Diameter

8 (133/29)

.432 (11.0)

.468 (11.9)

170 (253)

(37/26)

.298 (7.57)

.335 (8.51)

95.4 (142)

(19/25)

.238 (6.05)

.262 (6.65)

64.6 (96.1)

(19/27)

.196 (4.98)

.220 (5.59)

44.9 (66.8)

(19/29)

.166 (4.22)

.190 (4.83)

32.1 (47.8)

(19/30)

.152 (3.86)

.176 (4.47)

27.2 (40.5)

(19/32)

.132 (3.35)

.156 (3.96)

19.4 (28.9)

(19/34)

.114 (2.90)

.136 (3.45)

14.6 (21.7)

(19/36)

.102 (2.59)

.124 (3.15)

12.2 (18.2)

(19/38)

.092 (2.34)

.114 (2.90)

9.93 (14.8)

(7/36)

.082 (2.08)

.104 (2.64)

8.39 (12.5)

Component Wire

Shield

Jacket

Weight

AWG (Stranding)

Diameter

8 (133/29)

.222 (5.64)

.246 (6.25)

83.3 (124)

(37/26)

.155 (3.94)

.179 (4.55)

47.8 (71.1)

(19/25)

.127 (3.23)

.149 (3.78)

32.2 (47.9)

(19/27)

.106 (2.69)

.128 (3.25)

22.6 (33.6)

(19/29)

.091 (2.31)

.113 (2.87)

16.5 (24.6)

(19/30)

.084 (2.13)

.106 (2.69)

14.5 (21.6)

(19/32)

.074 (1.88)

.096 (2.44)

11.0 (16.4)

(19/34)

.065 (1.65)

.087 (2.21)

8.90 (13.2)

(19/36)

.059 (1.50)

.081 (2.06)

7.01 (10.4)

(19/38)

.054 (1.37)

.076 (1.93)

6.20 (9.23)

(7/36)

.049 (1.24)

.071 (1.80)

5.50 (8.19)
