Table 1. Pin function
#
Name
Function
Internal PU/PD
Type
1
CWUP
Cyclic wake-up input
PD
Local
2
GND2
Ground pin
-
Global
3
FAULTN
Open-drain fault output pin
-
Local
4
AUX1
Short to ground in application
-
Local
5
NCS
SPI chip select
PU
Local
6
SCLK
SPI clock
PD
Local
7
SDI
SPI data in (MOSI)
PD
Local
8
SDO
SPI data out (MISO)
-
Local
9
VIO
Digital output buffer supply input
-
Local
10
AUX2
Short to ground in application
-
Local
11
TM
ST test mode pin, short to ground in application
PD
Local
12
GND1
Ground pin
-
Global
13
AUX3
Open in application
PD
Local
14
FENH
Fire enable high-side
PU/PD (configurable)
Local
15
AUX4
Open in application
PD
Local
16
FENL
Fire enable low-side
PU/PD (configurable)
Local
17
PGND
Pyro-fuse driver low-side ground
-
Local
18
NC
No connection
-
Local
19
PR
Pyro-fuse driver low-side output
-
Global
20
NC
No connection
-
Local
21
PF
Pyro-fuse driver high-side output
-
Global
22
NC
No connection
-
Local
23
PS
Pyro-fuse driver high-side supply
-
Global
24
NC
No connection
-
Local
25
ERDCHSW
Energy reserve discharge switch
-
Local
26
NC
No connection
-
Local
27
ERBST
Main supply/energy reserve boost output
-
Global
28
NC
No connection
-
Local
29
BSTGND
Energy reserve boost ground
-
Local
30
ERBSTSW
Energy reserve boost switching node
-
Local
31
NC
No connection
-
Local
32
VBATMON
Input battery monitor pin
-
Global
33
EP
Exposed pad: connect to GND
-
-
L9965P
Block diagram and pin description
DS14702 - Rev 4
page 5/104
