Table 93. TQFP32L (7x7x1 mm 32+4L exposed pad down) package mechanical data
Symbol
Dimensions in mm
Min.
Typ.
Max.
Ө
0°
3.5
7°
Ө1
0°
-
-
Ө2
10°
12°
14°
Ө3
10°
12°
14°
A
-
-
1.20
A1
0.05
-
0.15
A2
0.95
1.00
1.05
b
0.30
0.37
0.45
b1
0.30
0.35
0.40
c
0.09
-
0.20
c1
0.09
-
0.16
D
9.00 BSC
D1
7.00 BSC
D2
-
-
5.37
D3
3.40
-
-
e
0.80 BSC
E
9.00 BSC
E1
7.00 BSC
E2
-
-
5.37
E3
3.40
-
-
L
0.45
0.60
0.75
L1
1.00 REF
N
32+4
R1
0.08
-
-
R2
0.08
-
0.20
S
0.20
-
-
Tolerance of form and position
aaa
0.20
bbb
0.20
ccc
0.10
ddd
0.20
L9965P
Package information
DS14702 - Rev 4
page 96/104
