L9965P Scheda tecnica(PDF) 43 Page - STMicroelectronics

Il numero della parte L9965P
Spiegazioni elettronici  Automotive single channel pyro-fuse driver
PDF  104 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Produttore elettronici  STMICROELECTRONICS [STMicroelectronics]
Homepage  http://www.st.com
Logo STMICROELECTRONICS - STMicroelectronics

L9965P Scheda tecnica(HTML) 43 Page - STMicroelectronics

Back Button L9965P Datasheet HTML 39Page - STMicroelectronics L9965P Datasheet HTML 40Page - STMicroelectronics L9965P Datasheet HTML 41Page - STMicroelectronics L9965P Datasheet HTML 42Page - STMicroelectronics L9965P Datasheet HTML 43Page - STMicroelectronics L9965P Datasheet HTML 44Page - STMicroelectronics L9965P Datasheet HTML 45Page - STMicroelectronics L9965P Datasheet HTML 46Page - STMicroelectronics L9965P Datasheet HTML 47Page - STMicroelectronics Next Button
Zoom Inzoom in Zoom Outzoom out
 43 / 104 page
background image
Table 24. VRCM STB/STG diagnostics
Fault
type
Assertion condition
IC reaction to
assertion
Release condition
IC reaction
to flag
clear
Maskable
LEAK
SINK
LOW
When IPF_PU is
enabled, if the STB
flag is not internally
set after
tVRCM_LEAK_FLT
expired, the
VRCM_STB_FAIL
fault is
acknowledged
The
VRCM_STB_FAIL
flag is set
FAULTN line is
asserted
Diagnostic routine is
stopped at the end of
the leakage current
test step
Cyclic diagnostic
triggers are inhibited
The
VRCM_STB_FAIL
flag can always be
cleared on read
FAULTN
line is
released
Cyclic
diagnostic
triggers are
unmasked
LEAK_EN = 0 masks cyclic
diagnostic trigger (but not the
on-demand one)
LEAK_LOW_FAULTN_MSK
masks fault redirection on
FAULTN pin
LEAK
SOURCE
LOW
When IPR_PD is
enabled, if the STG
flag is not internally
set after
tVRCM_LEAK_FLT
expired, the
VRCM_STG_FAIL
fault is
acknowledged
The
VRCM_STG_FAIL
flag is set
FAULTN line is
asserted
Diagnostic routine is
stopped at the end of
the leakage current
test step
Cyclic diagnostic
triggers are inhibited
The
VRCM_STG_FAIL
flag can always be
cleared on read
FAULTN
line is
released
Cyclic
diagnostic
triggers are
unmasked
LEAK_EN = 0 masks cyclic
diagnostic trigger (but not the
on-demand one)
LEAK_LOW_FAULTN_MSK
masks fault redirection on
FAULTN pin
L9965P
Functional description
DS14702 - Rev 4
page 43/104
