38 / 104 page  Symbol Parameter Test condition Min Typ Max Unit Pin EHS_DEPLOY_2 High side switch deployment energy capability Single event, VPS = 27.3 V IDEP = 2.23 A, tON = 851 µs RdsON_LS = 0 Ω, RWIRE = 0.1 Ω RPYRO = 1.7 Ω, TJ,START = 135 °C - - 44.2 mJ PS, PF EHS_DEPLOY_3 Single event, VPS = 27.3 V IDEP = 2.55 A, tON = 630 µs RdsON_LS = 0 Ω, RWIRE = 0.1 Ω RPYRO = 1.7 Ω, TJ,START = 135 °C - - 36.5 mJ PS, PF EHS_DEPLOY_4 Single event, VPS = 27.3 V IDEP = 4.46 A, tON = 289 µs RdsON_LS = 0 Ω, RWIRE = 0.1 Ω RPYRO = 1.7 Ω, TJ,START = 135 °C - - 24.9 mJ PS, PF RdsON_HS HS switch ON resistance ISINK = 100 mA - - 1 Ω PS, PF RdsON_LS LS switch ON resistance ISOURCE = 100 mA - - 1 Ω PR, PGND LWIRE Pyro-fuse wire load inductance Application information - - 36 µH PF, PR LEMI Pyro-fuse input EMI filter Application information - - 7.7 µH PF, PR RWIRE Pyro-fuse wire load resistance Application information - - 1.1 Ω PF, PR CPYRO Pyro-fuse differential capacitance between input contacts Application information - - 100 nF PF, PR RPYRO Pyro-fuse igniter resistance Application information 1.7 - 2.5 Ω PF, PR RPYRO_POST_0 Pyro-fuse igniter resistance threshold post deployment VRES_POST_TH = 0 - 99 - Ω PF, PR RPYRO_POST_1 VRES_POST_TH = 1 - 49 - Ω PF, PR CESD PF/PR PCB connector input capacitance for ESD/EMI Application information 13 22 138 nF PF, PR NHS_RET_00 HS deployment attempts HS_RET_CFG = 00 - 1 - times PR, PGND NHS_RET_01 HS_RET_CFG = 01 - 2 - times PR, PGND NHS_RET_10 HS_RET_CFG = 10 - 3 - times PR, PGND NHS_RET_11 HS_RET_CFG = 11 - 4 - times PR, PGND tHS_RET_00 HS delay between retry attempts HS_RET_DLY_CFG = 00 0.46 0.5 0.54 ms PR, PGND tHS_RET_01 HS_RET_DLY_CFG = 01 0.92 1 1.08 ms PR, PGND tHS_RET_10 HS_RET_DLY_CFG = 10 1.38 1.5 1.62 ms PR, PGND L9965P Functional description DS14702 - Rev 4 page 38/104 |
|
