Data Sheet

SSM4567

Rev. 0| Page 35 of 52

DAC CONTROL REGISTER

Address: 0x02, Reset: 0x32, Name: DAC_CTRL

Table 28. Bit Descriptions for DAC_CTRL

Bits

Bit Name

Settings

Description

Reset

Access

DAC_HV

DAC Hard Volume

0x0

R/W

Soft Volume Ramping

Hard/Immediate Volume Change

DAC_MUTE

DAC Mute Control

0x0

R/W

DAC Unmuted

DAC Muted

DAC_HPF

DAC High-Pass Filter Enable

0x1

R/W

DAC High-Pass Filter Off

DAC High-Pass Filter On

DAC_LPM

DAC Low Power Mode Enable

0x1

R/W

DAC Low Power Mode Off (128 × fs in PDM Mode)

DAC Low Power Mode On (64 × fs in PDM Mode)

RESERVED

Reserved.

0x0

R/W

[2:0]

DAC_FS

DAC Sample Rate Selection

0x2

R/W

000

8 kHz to 12 kHz Sample Rate

001

16 kHz to 24 kHz Sample Rate

010

32 kHz to 48 kHz Sample Rate

011

64 kHz to 96 kHz Sample Rate

100

128 kHz to 192 kHz Sample Rate

101

Reserved

110

Reserved

111

Reserved
