SSM4567
Data Sheet
Rev. 0| Page 14 of 52
Figure 33. Current Sense THD + N vs. Frequency, VBAT = 3. 6 V,
RL = 4 Ω and 15 µH
Figure 34. Output Spectrum of Sense ADC vs. Frequency
Output Power = 100 mW, RL = 8 Ω
0.001
0.01
0.1
1
10
10
100
1k
10k
100k
FREQUENCY (Hz)
POUT = 250mW
POUT = 500mW
POUT = 1W
POUT = 1.4W
–140
–120
–100
–80
–60
–40
–20
0
20
200
2k
20k
FREQUENCY (Hz)
ISENSE
VSENSE
