Data Sheet

SSM4567

Rev. 0| Page 41 of 52

SERIAL AUDIO INTERFACE PLACEMENT 3 CONTROL REGISTER

Address: 0x08, Reset: 0x32, Name: SAI_PLACEMENT_3

Table 34. Bit Descriptions for SAI_PLACEMENT_3

Bits

Bit Name

Settings

Description

Reset

Access

[7:6]

RESERVED

Reserved.

0x0

R/W

[5:4]

P3_DAC

Placement 3 or L2 (Left 2) Control for DAC Input. Selects the size of the data to be read.

24 bits or 16 bits. This slot can also be set to read in eight bits, throw them away, and

move on to placement P4 to read the audio data.

0x3

R/W

24-Bit DAC Input

16-Bit DAC Input

Read and Ignore 8 bits

RESERVED

Reserved.

0x0

R/W

[2:0]

P3_SNS

Placement 3 or L2 (Left 2) Control for Sense Output.

0x2

R/W

000

16-Bit Voltage Output

001

16-Bit Current Output

010

8-Bit Battery Voltage Output Unsigned

011

8-Bit Control Data Output

100

Alternating 16-Bit Voltage and Current

101

8-Bit Status Output

110

8-Bit V/I Marker and Slot ID

111

Blank 8 Bits
