Low power DP to VGA adapter with integrated 1 : 2 VGA switch

13. Characteristics

13.1 Current consumption, power dissipation and thermal characteristics

[1]

VGA monitor remains connected at power-on — this condition is applicable only when PTN3355 is used in most interoperable

(non-compliant) HPD mode (that is, CFG1_SCL/CFG2_SDA is ‘01’ or ‘10’).

Table 13.

Current consumption, power dissipation and thermal characteristics

Over operating free-air temperature range, unless otherwise noted.

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

IDD

supply current

normal operation, WUXGA / 193 MHz pixel

clock; VDD(3V3) =3.3 V

-60

-mA

Low power D3 mode; VDD(3V3) =3.3 V

-

124

-

A

P

power dissipation

normal operation, WUXGA / 193 MHz pixel clock

(reduced blanking)

Buck converter mode;

PTN3355 being used as per Figure 4

-200

-mW

LDO mode;

PTN3355 being used as per Figure 5

-405

-mW

Rth(j-a)

thermal resistance from

junction to ambient

in free air for SOT618-1

-

45

-

K/W

Table 14.

Device characteristics

Over operating free-air temperature range, unless otherwise noted.

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

tstartup

start-up time

device start-up time from power-on to HPD = HIGH;

VGA monitor remains connected at power-on[1];

RST_N = HIGH; supply voltage within operating range to

specified operating characteristics

--100

ms

tw(rst)

reset pulse width

device is supplied with valid supply voltage

10

-

-

s

td(rst)

reset delay time

device reset delay time from RST_N toggling (LOW to

HIGH) until HPD goes HIGH;

VGA monitor remains connected at power-on[1];

supply voltage within operating range to specified

operating characteristics

--100

ms
