Low power DP to VGA adapter with integrated 1 : 2 VGA switch

19. References

[1]

VESA DisplayPort Standard — Version 1, Revision 2a; March 2012

[2]

Display Data Channel Command Interface Standard — Version 1.1;

October 29, 2004

[3]

Video Signal Standard (VSIS) — Version 1, Rev. 2; December 12, 2002

[4]

IEC 61000-4-2, Electromagnetic compatibility (EMC) - Part 4-2: Testing and

measurement techniques — ElectroStatic Discharge (ESD) immunity test,

edition 2.0, 2008-12

20. Revision history

UXGA

Ultra eXtended Graphics Array

VESA

Video Electronics Standards Association

VGA

Video Graphics Array

VSIS

Video Signal Interface Standard

WUXGA

Wide Ultra eXtended Graphics Array

XGA

eXtended Graphics Array

Table 29.

Abbreviations …continued

Acronym

Description

Table 30.

Revision history

Document ID

Release date

Data sheet status

Change notice

Supersedes

PTN3355 v.3.1

20161104

Product data sheet

PTN3355 v.3

Modifications:

• Section 7: Deleted last sentence in last paragraph referencing programming document; there is no

programming document.

PTN3355 v.3

20140714

Product data sheet

PTN3355 v.2

Modifications:

• Updated Figure 4

PTN3355 v.2

20140703

Product data sheet

PTN3355 v.1

20140310

Product data sheet
