32 / 37 page  PTN3355 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2016. All rights reserved. Product data sheet Rev. 3.1 — 4 November 2016 32 of 37 NXP Semiconductors PTN3355 Low power DP to VGA adapter with integrated 1 : 2 VGA switch 17. Soldering: PCB footprints Fig 16. PCB footprint for SOT618-1 (HVQFN40); reflow soldering SOT618-1 Footprint information for reflow soldering of HVQFN40 package sot618-1_fr occupied area solder paste solder resist solder lands Dimensions in mm Ay Bx D SLx SLy SPy tot P 7.000 5.200 By 5.200 0.900 0.290 C 4.100 4.100 2.400 SPx tot 2.400 SPx 0.600 SPy 0.600 Gx 6.300 Gy 6.300 Hx 7.250 Hy 7.250 0.500 Ax 7.000 nSPx 3 nSPy 3 Issue date 09-06-11 14-08-13 Ax Bx SLx Gx Gy Hy Hx Ay By SLy P 0.025 0.025 D (0.105) SPx tot nSPx nSPy SPx SPy C Generic footprint pattern Refer to the package outline drawing for actual layout |
|
