PTN3355

All information provided in this document is subject to legal disclaimers.

Product data sheet

Rev. 3.1 — 4 November 2016

25 of 37

NXP Semiconductors

PTN3355

Low power DP to VGA adapter with integrated 1 : 2 VGA switch

14. Package outline

Fig 9.

Package outline SOT618-1 (HVQFN40)

References

Outline

version

European

projection

Issue date

IEC

JEDEC

JEITA

SOT618-1

MO-220

sot618-1_po

02-10-22

13-11-05

Unit

max

nom

min

1.00

0.05

0.2

6.1

4.25

6.1

0.4

A(1)

Dimensions (mm are the original dimensions)

Note

1. Plastic or metal protrusions of 0.075 mm maximum per side are not included.

HVQFN40: plastic thermal enhanced very thin quad flat package; no leads;

40 terminals; body 6 x 6 x 0.85 mm

SOT618-1

0.30

cD(1)

E(1)

4.10

ee1

0.05

0.1

0.85

0.02

6.0

4.10

6.0

0.21

0.3

3.95

0.80

0.00

5.9

3.95

5.9

0.18

0.5

4.5

0.5

4.25

4.5

0.1

1/2 e

terminal 1

index area

terminal 1

index area

2.5

5 mm

scale

detail X
