15 / 37 page  PTN3355 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2016. All rights reserved. Product data sheet Rev. 3.1 — 4 November 2016 15 of 37 NXP Semiconductors PTN3355 Low power DP to VGA adapter with integrated 1 : 2 VGA switch 10.1 Display resolution Table 9 lists some example display resolutions and clock rates that PTN3355 supports. (Refer to Footnote 1 on page 2.) [1] Contact NXP team for other monitor timings not listed in this table. The available bandwidth over a 2-lane HBR DisplayPort v1.2a link limits pixel clock rate support to: • 240 MHz at 6 bpc • 180 MHz at 8 bpc Table 9. Display resolution and pixel clock rate[1] Display type Active video Total frame Bits per pixel Vertical frequency (Hz) Pixel clock (MHz) Data rate (Gbit/s) Standard type Horizontal Vertical Horizontal total (pixel) Vertical total (line) VGA 640 480 800 525 24 59.94 25.175 0.76 Industry standard SVGA 800 600 1056 628 24 60.317 40.000 1.20 VESA guidelines XGA 1024 768 1344 806 24 60.004 65.000 1.95 VESA guidelines XGA+ 1152 864 1600 900 24 75 108.000 3.24 VESA standard HD 1360 768 1792 795 24 60.015 85.500 2.56 VESA standard HD/WXGA 1366 768 1792 798 24 59.79 85.501 2.57 VESA standard HD/WXGA 1280 720 1650 750 24 60 74.250 2.23 CEA standard WXGA 1280 800 1680 831 24 59.81 83.500 2.50 CVT WXGA 1280 800 1696 838 24 74.934 106.500 3.19 CVT WXGA 1280 800 1712 843 24 84.88 122.500 3.68 CVT SXGA 1280 960 1800 1000 24 60 108.000 3.24 VESA standard SXGA 1280 1024 1688 1066 24 60.02 108.000 3.24 VESA standard SXGA 1280 1024 1688 1066 24 75.025 135.001 4.05 VESA standard SXGA 1280 1024 1728 1072 24 85.024 157.500 4.72 VESA standard SXGA+ 1400 1050 1864 1089 24 59.978 121.749 3.65 CVT WXGA+ 1440 900 1904 934 24 59.887 106.499 3.19 CVT HD+ 1600 900 1800 1000 24 60 (RB) 108.000 3.24 VESA standard UXGA 1600 1200 2160 1250 24 60 162.000 4.86 VESA standard UXGA 1600 1200 2160 1250 24 65 175.500 5.27 VESA standard WSXGA+ 1680 1050 2240 1089 24 59.954 146.249 4.39 CVT FHD 1920 1080 2200 1125 24 60 148.500 4.46 CEA standard WUXGA 1920 1200 2592 1245 18 59.885 193.251 4.35 CVT WUXGA 1920 1200 2080 1235 24 59.95 (RB) 154.000 4.62 CVT RB 2.76M3 1920 1440 2600 1500 18 60 234.000 5.27 VESA standard QWXGA 2048 1152 2250 1200 24 60 (RB) 162.000 4.86 CVT RB QXGA 2048 1536 2128 1573 24 49.95 (RB) 167.20 5.02 CVT RB |
|
