PTN3355

Low power DP to VGA adapter with integrated 1 : 2 VGA switch

[1]

HVQFN40 package die supply ground is connected to exposed center pad. Exposed center pad must be connected to supply ground for

proper device operation. For enhanced thermal, electrical, and board level performance, the exposed pad must be soldered to the board

using a corresponding thermal pad on the board and for proper heat conduction through the board, thermal vias must be incorporated in

the PCB in the thermal pad region.

ML1_N

10

self-biasing differential

input

DisplayPort Main Link lane 1 negative input

RST_N

11

3.3 V digital input

Reset input active LOW; pulled up to VDD(3V3) internally

DDC_SDA2

12

5 V open-drain I/O

DDC I2C-bus data for channel 2

HPD

13

3.3 V digital I/O

DisplayPort Hot Plug Detection output

CFG1_SCL

14

5 V open-drain I/O

General purpose configuration pin CFG1 or slave I2Cclock

CFG5

15

3.3 V digital I/O

Configuration pin supporting trinary input

CFG3

16

3.3 V digital I/O

Reserved

CFG2_SDA

17

5 V open-drain I/O

General purpose configuration pin CFG2 or slave I2Cdata

VSYNC2

18

3.3 V 50

 digital I/O

Vertical sync for channel 2

HSYNC2

19

3.3 V 50

 digital I/O

Horizontal sync for channel 2

DDC_SCL1

20

5 V open-drain I/O

DDC I2C-bus clock for channel 1

VDDE33_IO

21

power

3.3 V power supply for I/O

DDC_SDA1

22

5 V open-drain I/O

DDC I2C-bus data for channel 1

DDC_SCL2

23

5 V open-drain I/O

DDC I2C-bus clock for channel 2

VSYNC1

24

3.3 V 50

 digital I/O

Vertical sync for channel 1

HSYNC1

25

3.3 V 50

 digital I/O

Horizontal sync for channel 1

BLU1

26

analog output

Blue DAC analog output for channel 1

BLU2

27

analog output

Blue DAC analog output for channel 2

GRN1

28

analog output

Green DAC analog output for channel 1

GRN2

29

analog output

Green DAC analog output for channel 2

RSET

30

input

Resistor for DAC output reference control

RED1

31

analog output

Red DAC analog output for channel 1

RED2

32

analog output

Red DAC analog output for channel 2

OSC_IN

33

input

Crystal oscillator input

OSC_OUT

34

output

Crystal oscillator output

VDDA15_DAC

35

power

1.5 V power supply for DAC; power provided to this pin from SWOUT

pin

VDDD15

36

power

1.5 V power supply for digital core; power provided to this pin from

SWOUT pin

TESTMODE

37

input

Test mode selection for CFG/JTAG and I2C slave address selection;

supports trinary input

PVDD33

38

power

3.3 V power supply for switching regulator

SWOUT

39

power

Switching regulator output

PGND

40

ground

Ground for switching regulator

GND[1]

-

power

central supply ground connection (exposed die pad)

Table 3.

Pin description …continued

Symbol

Pin

Type

Description
