R34DS0017EU0104 Rev.1.04

Page 9

Jan 31, 2025

ISL73041SEH Datasheet

AVCC Undervoltage Lockout (UVLO)

AVCC UVLO Rising

Threshold

VRAVCC

Test by recovering AVCC from

constant current limit

-55 to

+125°C

4.46

4.6

4.74

V

AVCC UVLO Falling

Threshold

VFAVCC

Test by putting AVCC into constant

current limit

4.28

4.41

4.52

V

AVCC UVLO Hysteresis

VHAVCC

VRAVCC - VFAVCC

150

183

300

mV

PVCC Undervoltage Lockout (UVLO)

PVCC UVLO Rising

Threshold

VRPVCC

PVCC = 5.5V with FB resistors[3]

-55 to

+125°C

5.21

5.34

5.45

V

PVCC UVLO Falling

Threshold

VFPVCC

PVCC = 5.5V with FB resistors[3]

5.07

5.17

5.27

V

PVCC UVLO Hysteresis

VHPVCC

VRPVCC - VFPVCC

100

150

300

mV

BOOT Undervoltage Lockout (UVLO)

BOOT UVLO Rising

Threshold

VRBOOT

-

-55 to

+125°C

3.8

4.0

4.2

V

BOOT UVLO Falling

Threshold

VFBOOT

-

3.6

3.8

4.0

V

BOOT UVLO Hysteresis

VHBOOT

VRBOOT - VFBOOT

100

240

400

mV

PWM and EN Input Pins

EN High Level Threshold

VIHEN

PWM = 0V

-55 to

+125°C

-1.8

2.0

V

EN Low Level Threshold

VILEN

PWM = 0V

1.0

1.5

-

V

EN Input Hysteresis

VHYSEN

VIHEN - VILEN

100

325

400

mV

PWM High Threshold

VPWMH

VDD = 4.75V to 13.2V

-55 to

+125°C

-2.7

2.8

V

PWM Middle Level Range

VPWMM

VDD = 4.75V to 13.2V

1.45

-

2.4

V

PWM Low Threshold

VPWML

VDD = 4.75V to 13.2V

0.95

1.1

-

V

Mid-High Level Hysteresis

-

VDD = 4.75V to 13.2V

-

100

200

mV

Mid-Low Level Hysteresis

-

VDD = 4.75V to 13.2V

-

200

350

mV

PWM High Input Current

IPWMH

PWM = 5V

10

33

50

µA

PWM Low Input Current

IPWML

PWM = 0V

-50

-22

-10

µA

PWM Pin Pull-Up Resistor

RPWMU

-

150

225

300

kΩ

PWM Pin Pull-Down

Resistor

RPWML

-

100

150

200

kΩ

PWM Pin Floating Voltage

VFLOAT

-

1.90

2.0

2.135

V

Unless otherwise specified: VDD = 13.2V; EN = VDD; PVCC = 5.5V; CPVCC = 2.2µF; CAVCC =2.2µF; CBOOT = 100nF to PHS;

PHS = PGND = 0V; TA= 25°C. UG is defined as UGH = UGL. LG is defined as LGH = LGL. Boldface specifications apply across

the operating temperature range from -55°C to +125°C and across a total ionizing dose of 75krad(Si) at +25°C with exposure

at a low dose rate of <10mrad(Si)/s. (Cont.)

Parameter

Symbol

Test Conditions

Temp.

Min[1]

Typ.[2]

Max[1]

Unit
