R34DS0017EU0104 Rev.1.04
Page 16
Jan 31, 2025
ISL73041SEH Datasheet
3.5
Timing Diagrams
Figure 4. PWM Propagation Delay
Figure 5. Programmable Dead Time
Figure 6. PWM Mid Level Propagation Delay
Figure 7. PVCC UVLO to FLT Propagation Delay
Figure 8. PVCC UVLO to UG & LG Propagation Delay
Figure 9. BOOT UVLO to UG Propagation Delay
PWM
VPWMH
VPWML
tPDLG
50%
50%
tPDUG
Propagation Delay Matching: tPDLG - tPDUG
LG
UG
tDT_LU
50%
50%
50%
50%
tDT_UL
LG
UG
Dead Time Set by Resistor Value on the RDU/RDL Pin
Programmable Dead Time Matching: tDT_LU - tDT_UL
PWM
LG
UG
tPDUG1
VMIDL
VPWMH
tPDLG1
50%
50%
tPDUG2
tPDLG2
50%
50%
VMIDH
VPWML
PVCC
PVCC UVLO Fall
PVCC UVLO Rise
UG and LG Outputs
respond to PWM = 0V or
PWM = 5V
t_PVCCR
t_PVCCF
FLT
UG and LG Outputs do not
respond to PWM = 0V or
PWM = 5V
PVCC
PVCC UVLO Fall
PVCC UVLO Rise
UG and LG Outputs
respond to PWM = 0V
or PWM = 5V
t_PVCCR
t_PVCCF
UG and LG
Output
UG and LG Outputs don’t
respond to PWM = 0V or
PWM = 5V
BOOT
BOOT UVLO Fall
BOOT UVLO Rise
UG Respond to
PWM = 5V
t_BOOTR
t_BOOTF
UG Output does not
respond to PWM = 5V
UG
