SSM2529
Data Sheet
Rev. 0 | Page 30 of 52
CHANNEL MAPPING CONTROL REGISTER
Table 52. Address: 0x04, Reset: 0x10, Name: Channel Mapping Control
Bits
Bit Name
Settings
Description
Reset
Access
[7:4]
CH_SEL_R
Right channel mapping select
0x1
RW
0000
Channel 0 from SAI to right output
0001
Channel 1 from SAI to right output
0010
Channel 2 from SAI to right output
0011
Channel 3 from SAI to right output
0100
Channel 4 from SAI to right output
0101
Channel 5 from SAI to right output
0110
Channel 6 from SAI to right output
0111
Channel 7 from SAI to right output
1000
Channel 8 from SAI to right output
1001
Channel 9 from SAI to right output
1010
Channel 10 from SAI to right output
1011
Channel 11 from SAI to right output
1100
Channel 12 from SAI to right output
1101
Channel 13 from SAI to right output
1110
Channel 14 from SAI to right output
1111
Channel 15 from SAI to right output
[3:0]
CH_SEL_L
Left channel mapping select
0x0
RW
0000
Channel 0 from SAI to left output
0001
Channel 1 from SAI to left output
0010
Channel 2 from SAI to left output
0011
Channel 3 from SAI to left output
0100
Channel 4 from SAI to left output
0101
Channel 5 from SAI to left output
0110
Channel 6 from SAI to left output
0111
Channel 7 from SAI to left output
1000
Channel 8 from SAI to left output
1001
Channel 9 from SAI to left output
1010
Channel 10 from SAI to left output
1011
Channel 11 from SAI to left output
1100
Channel 12 from SAI to left output
1101
Channel 13 from SAI to left output
1110
Channel 14 from SAI to left output
1111
Channel 15 from SAI to left output
