background image
SSM2529
Data Sheet
Rev. 0 | Page 34 of 52
FAULT_CTRL1 REGISTER
Table 63. Address: 0x0F, Reset: 0x00, Name: FAULT_CTRL1
Bits
Bit Name
Settings
Description
Reset
Access
[7:5]
Reserved
0x0
RW
4
PDB_LINE
Single end lineout enable
0x0
RW
0
Disabled
1
Enabled
3
PDB_ZC
Lineout calibration enable
0x0
RW
0
Disabled
1
Enabled
2
CLK_LOSS
Clock for DAC and Class-D lost
0x0
R
0
Normal operation
1
Loss of clock signal
1
OC
Right channel overcurrent fault
0x0
R
0
Normal operation
1
Right channel overcurrent fault
0
OT
Overtemperture fault status
0x0
R
0
Normal operation
1
Overtemperature fault
FAULT_CTRL2 REGISTER
Table 64. Address: 0x10, Reset: 0x4C, Name: FAULT_CTRL2
Bits
Bit Name
Settings
Description
Reset
Access
7
Reserved
0x0
RW
[6:5]
AR_TIME
Auto recovery time
0x2
RW
00
10 ms auto fault recovery delay
01
20 ms auto fault recovery delay
10
40 ms auto fault recovery delay
11
80 ms auto fault recovery delay
4
MRCV
Manual fault recovery
0x0
RW
1
Writing of 1 causes a manual fault recovery attempt when ARCV = 11
[3:2]
MAX_AR
Maximum fault recovery attempts
0x3
RW
00
1 auto recovery attempt
01
3 auto recovery attempts
10
7 auto recovery attempts
11
Unlimited auto recovery attempts
[1:0]
ARCV
Auto fault recovery control
0x0
RW
00
Auto fault recovery for overtemperature and overcurrent faults
01
Auto fault recovery for overtemperature fault only
10
Auto fault recovery for overcurrent fault only
11
No auto fault recovery
DEEMP_CTRL REGISTER
Table 65. Address: 0x14, Reset: 0x00, Name: DEEMP_CTRL
Bits
Bit Name
Settings
Description
Reset
Access
[7:3]
Reserved
0x00
RW
[2:1]
DEEMP_FS
De-emphasis sample rate selection
0x0
RW
00
Set coefficients to all zero
01
48 kHz
10
44.1 kHz
11
32 kHz
0
DEEMP_EN
De-emphasis enable
0x0
RW
1
De-emphasis filter enable
0
De-emphasis filter disable
