46 / 52 page  SSM2529 Data Sheet Rev. 0 | Page 46 of 52 DRC_HOLD_TIME REGISTER Table 139. Address: 0x5E, Reset: 0x00, Name: DRC_HOLD_TIME Bits Bit Name Settings Description Reset Access [7:4] DRCHTNG DRC hold time for noise gating 0x0 RW 0000 0 ms(default) 0001 0.67 ms xxxx Double time 0111 42.67 ms 1111 43.7 sec [3:0] DRCHTNOR DRC hold time for normal operation 0x0 RW 0000 0 ms(default) 0001 0.67 ms xxxx Double time 0111 42.67 ms 1111 43.7 sec DRC_RIPPLE_CTRL REGISTER Table 140. Address: 0x5F, Reset: 0x00, Name: DRC_RIPPLE_CTRL Bits Bit Name Settings Description Reset Access [7:2] Reserved 0x0 RW [1:0] DRCRRH DRC ripple remove threshold 0x0 RW 00 0 dB (default) 01 0.28 dB 10 0.47 dB 11 0.75 dB DRC MODE CONTROL REGISTER Table 141. Address: 0x60, Reset: 0x3C, Name: DRC Mode Control Bits Bit Name Settings Description Reset Access 7 VBAT_EN VBAT tracking enable 0x0 RW 0 VBAT tracking disable 1 VBAT tracking enable 6 LIM_SRC Limiter source selection 0x0 RW 0 RMS 1 Peak 5 LIM_EN Limiter enable 0x1 RW 0 Limiter function disabled 1 Limiter function enabled 4 COMP_EN Compressor enable 0x1 RW 0 Compressor function disabled 1 Compressor function enabled 3 EXP_EN Expander enable 0x1 RW 0 Expander function disabled 1 Expander function enabled 2 NG_EN Noise gate enable 0x1 RW 0 Noise gate function disabled 1 Noise gate function enabled [1:0] DRC_EN DRC enable 0x0 RW 0 DRC disabled 1 DRC enabled |
|
