SSM2529ACBZ-R7 Scheda tecnica(PDF) 47 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
SSM2529ACBZ-R7 Scheda tecnica(HTML) 47 Page - Analog Devices |
|
|
47 / 52 page  Data Sheet SSM2529 Rev. 0 | Page 47 of 52 FDSP_EN REGISTER Table 142. Address: 0x61, Reset: 0x00, Name: FDSP_EN Bits Bit Name Settings Description Reset Access [7:1] Reserved 0x00 RW 0 FDSP_EN FDSP enable 0x0 RW 0 Disable FDSP 1 Enable FDSP SPK_PROT_EN REGISTER Table 143. Address: 0x80, Reset: 0x00, Name: SPK_PROT_EN Bits Bit Name Settings Description Reset Access [7:1] Reserved 0x00 RW 0 SP_EN Speaker protection enable 0x0 RW 0 Speaker protection disabled (default) 1 Speaker protection enabled TEMP_AMBIENT REGISTER Table 144. Address: 0x81, Reset: 0x19, Name: TEMP_AMBIENT Bits Bit Name Settings Description Reset Access [7:0] TEMP_AMBIENT Ambient temperature in degrees Celsius (8.0 integer format) 0x19 RW 0x19 25°C (default) 0x20 32°C SPKR_DCR REGISTER Table 145. Address: 0x82, Reset: 0x40, Name: SPKR_DCR Bits Bit Name Settings Description Reset Access [7:0] SPKR_DCR Nominal speaker dc resistance in ohms (5.3 unsigned format) 0x40 RW 0x34 6.5 Ω 0x40 8 Ω (default) SPKR_TC REGISTER Table 146. Address: 0x83, Reset: 0x08, Name: SPKR_TC Bits Bit Name Settings Description Reset Access [7:0] SPKR_TC Nominal speaker temperature coefficient, rise in ohms per degrees Celsius (0.8 fractional format). 0x08 RW 0x08 0.033 Ω/°C (default) 0x0A 0.04 Ω/°C SP_CF1_H REGISTER Table 147. Address: 0x84, Reset: 0x3F, Name: SP_CF1_H Bits Bit Name Settings Description Reset Access [7:0] SP_CF1_H Default Speaker Temperature Model Coefficient 1, Bits[15:8] in 0.8 fractional format 0x3F RW SP_CF1_L REGISTER Table 148. Address: 0x85, Reset: 0x81, Name: SP_CF1_L Bits Bit Name Settings Description Reset Access [7:0] SP_CF1_L Default Speaker Temperature Model Coefficient 1, Bits[7:0] in 0.8 fractional format 0x81 RW SP_CF2_H REGISTER Table 149. Address: 0x86, Reset: 0x00, Name: SP_CF2_H Bits Bit Name Settings Description Reset Access [7:0] SP_CF2_H Default Speaker Temperature Model Coefficient 2, Bits[15:8] in 0.8 fractional format 0x00 RW |
|
